Flexible bank of LED for use in slim-line applications. Quick and easy to install.

Product Specs

  • Power Output

    11.5W (12V)

  • Lumens

    860lm

  • Colours Available

    3000K, 6500K

  • Warranty

    5 Years

  • Dimensions

    480 x 240 x 8mm

  • Max Series

    6 Units per Series

  • Includes

    2 Panels Per Pack

The Matrix Panel is a flexible bank of LED lights for use in slim-line light-box applications (30 to 80 mm depth).

The panel can be cut every 60mm and joined with included connectors to make up the required size and shape. With solder-free assembly and pre-mounted 3M double sided tape, installation is quick and easy.

Find all the latest product specifications and guides below:

Units

, , ,

Colour

3000K, 6500K
IP Rating

Product Type

LED Panel
Voltage

12V
Power Output

11.5W Per Panel
Features

Dimmable

Installation guide

1
Ensure lightbox surface is clean and free from debris. We recommend ensuring the internal surfaces are painted matte white to encourage illumination.
2
Arrange matrix spectrum panels in a grid-like fashion within the light box. Measure and trim panels to desired size, ensuring to only trim the panels at the marked cut lines.
3
Remove double sided tape and firmly press panels in place.
4
Connect panels together using included connectors, ensuring to not exceed the maximum series. Wire panels in parallel if required to avoid voltage drop.
5
Connect the panels the transformer and power up, testing to ensured they are wired up correctly.

Warning

Risk of electrical shock. Please read these instructions completely and carefully. Disconnect power before servicing or installing product.
